Standard features

• R410A

Executions:

• > Heatpump for cooling and heating with total heat recovery (for 4-pipe …plants)
• > Multipurpose heatpump for heating, cooling and DHW production (for …2-pipe plants)

Versions:

• > Standard
• > Low-Noise

Refrigerating circuit executions:

• > EP1: 2 compressors in 2 separated circuits from 110 to 180 kW
• > EP2: 2 compressors in 1 single circuit from 45 to 180 kW
• > EP3: 3 compressors in 1 single circuit from 230 to 270 kW
• > EP4: 4 compressors in 2 separated circuits from 130 to 430 kW
• MultiScroll solution for high efficiency performances with partial loads ..(E.S.E.E.R.)
• Single refrigerating circuit (single compressor up to 20 kW; two compressors from 20 kW)
• Electronic driven electrical expansion valve
• AISI 316 stainless steel brazed plate heat exchangers
• Electrical panel with main switch
• Filter dryers with removable cartridge
• Sight Glass
• Safeties according to PED 97/23

Options and accessories

• Water pump (low- or high-pressure) installed in an additional hydraulic …module
• Two 4-way valves kit on the water side to keep the heat exchange in …counterflow — installed in an additional hydraulic module
• Serial cards for protocols: Carel / Modbus / Lonworks / Trend
• HIWEB Hardware: Ethernet card for protocols: Bacnet / SNMP
• HIWEB Software: Ethernet card for Web connectivity
• GSM Modem for SMS communication
• LAN connection up to 4 units
• Touch-Screen colour graphic display
• Softstarter kit
