Standard features

• R410A

Executions:

• > Heatpump for cooling and heating with total heat recovery (for 4-pipe …plants)
• > Multipurpose heatpump for heating, cooling and DHW production (for …2-pipe plants)

Versions:

• > Standard
• > Low-Noise

• Two independent refrigerating circuits
• MultiScroll solution for high efficiency performances with partial loads …(E.S.E.E.R.)
• Electronic driven electrical expansion valve
• AISI 316 stainless steel brazed plate heat exchanger
• Electrical panel with main switch
• Filter dryers with removable cartridge
• Sight Glass
• Two separated fan section
• Smart defrost system
• Safeties according to PED 97/23
• Condensing control
• Hydrophilic treatment for the coils

Options and accessories

• Water pump (low- or high-pressure)

  …Double water pump kit:

  • > OR: low- or high-pressure, with one single pump working. Stand-by & …rotation mode pump management.
  • > AND: low- or high-pressure, with both pumps working simultaneously. …With partial loads one pump works with 67% of the nominal water- flow = …power consumption is reduced of 30%.
• Buffer tank on board
• EC fans
• Serial cards for protocols: Carel / Modbus / Lonworks / Trend
• HIWEB Hardware: Ethernet card for protocols: Bacnet / SNMP
• HIWEB Software: Ethernet card for Web connectivity
• GSM Modem for SMS communication
• LAN connection up to 4 units
• Touch-Screen colour graphic display
• Softstarter kit
